AAR CV Axle Shaft for 2019-2023 Audi (e-tron Quattro, e-tron S, e-tron S Sportback, e-tron Sportback) AD-86018
Always the correct part
Call or Chat
30-Day Returns Accepted
Free Ground Shipping
The TrakMotive AAR CV Axle Shaft (part number AD-86021) is a direct-fit replacement for 2016-2018 Audi vehicles with 1.4L engines.
Specifications:
| ABS Tone Ring Tooth Quantity | 0 |
| ABS Tone Ring Included | No |
| Overall Compressed Length (mm) | 545 |
| Overall Compressed Length (in) | 21.44 |
| Outboard Joint Type | Audi Style Spline Bolt |
| Outboard Shaft Connection Style | Audi Style Spline Bolt |
| Number Of Outboard Splines | 36 |
| Axle Nut Included | No |
| Number Of Inboard Splines | 37 |
| Overall Extended Length (mm) | 596 |
| Overall Extended Length (in) | 23.5 |
| Outboard Joint Boot Material | Neoprene |
| Inboard Joint Boot Material | Neoprene |
| Number Of Bolt Holes | 1 |
Fits: 2016-2018 Audi models including A3 Sportback e-tron - 1.4L engines. Confirm your year, make, model, and engine before ordering.
Fitment Notes: OE AAR design
