The CSF Radiator (part number 3242) is a direct-fit replacement for 1996-2015 Chevrolet, GMC, and Isuzu vehicles with 6.0L and 5.7L engines.
Features:
- OEM specified Plastic Tank-Aluminum Core Construction
- Tanks are made from Virgin Grade Engineered plastic resins, which are "Glass Filled" for added Strength & Durability
- Gaskets are made from Special Grade "EPDM" rubber to withstand extreme temperatures of up to -120 Degrees F
- Tubes - Welded Type or Latest Generation "B-Tube" Design
- Fins (Heart of Radiator) - High Performance "Multi-Louvered Design" - OEM Spec
- 100% leak tested before leaving factory at 150% of operating pressure
- Industry Best Packaging - "10 Foot Drop Test" Standard
- Drop-in Fit
Specifications:
| Box Length (in) | 30 1/4 |
| Box Width (in) | 28 11/16 |
| Box Height (in) | 7 7/16 |
| Box Weight (lbs) | 21 |
| Inlet Length (in) | 22 1/8 |
| Inlet Width (in) | 1 15/16 |
| Outlet Length (in) | 22 1/8 |
| Outlet Width (in) | 1 15/16 |
| No. Of Rows | 2 |
| Oil Cooler (in) | 12 (high-efficiency Plate Type) |
| Radiator Cap Supplied | No |
| Csf Cap Number | 4503 |
| Hazardous Material | No |
| Tech Note | O.E.M. Style Radiator; Superior Engineered Multifit model with Sensor Port on top tank |
Fits: 1996-2015 Chevrolet, GMC, and Isuzu models including W3500 Tiltmaster, W4500 Tiltmaster, W3500 Forward, W4500 Forward, NPR, NPR-HD - 6.0L and 5.7L engines. Confirm your year, make, model, and engine before ordering.
Interchanges With: OEM Part Number 97143373, OEM Part Number 97179328, OEM Part Number 97214669, OEM Part Number 97222913, OEM Part Number 97311558, OEM Part Number 8-97143-373-1, OEM Part Number 8-97179-328-2, OEM Part Number 8-97214-669-0 and 4 more
