The Enginetech RCSZ1.6P Engine Rebuild Kit is a complete overhaul package for the 1996-2001 Suzuki 1.6L 4-Cyl (97 cid), machined to a 2.975" finished bore (.020" over bore).
Kit contents:
- P4630(4) - Piston Set
- C75154 - Piston Ring Set
- BB8340 - Bearing Set - Rod
- BC8339 - Bearing Set - Main
- TW8339 - Thrust Washer
- SU1.6HS-A - Gasket Set - Head
- SU1.6CS - Gasket Set - Lower
- TB212 - Timing Belt
- TT282 - Timing Belt Tensioner
- EP005A - Oil Pump
Component specifications:
- P4630(4) - Pistons: Dish top. 1.114 Compression Height
- C75154 - Piston rings: Premium. Steel top. 1.2 / 1.5 / 2.8mm ring stack
- EP005A - Oil Pump: rotary-type, aluminum housing, standard volume / standard pressure, 7-bolt mount
Bearing sizing: Select your rod and main bearing size. Rod and main bearings are supplied at the same size; contact us for different or split sizes.
Fits 1996-2001 1.6L 97 4-Cyl engines for Suzuki Sidekick, Suzuki Vitara, Suzuki X-90, and more. Verify fitment for your specific vehicle.
