The Enginetech EB001-4 is a set of bronze (copper/lead alloy) piston pin bushings supplied as a 4 pack. Fits 1975-1995 Toyota 2.2L/2.4L applications.
Important Notes
- Sold as a 4 Pack - one complete set for an L4 engine. Order additional packs for multiple engines.
- Supplied semi-finished on the inside diameter: the bushing ID must be final-reamed or honed to match the wrist pin after pressing into the connecting rod small end. This is a standard machine-shop operation and establishes the running clearance on the pin.
- Bronze (copper/lead alloy) construction matches OE material spec for durability and anti-seizure performance under high cyclic loads at the rod small end.
- Direct OEM cross-reference replacement - see the OEM Cross-References section below for matching part numbers.
- Always verify the OE bushing ID, OD, length, and rod part number against the original bushing being replaced before installation. Dimensions vary across engine families even when sharing similar makes or displacements.
Specifications
| Part Number | EB001-4 |
| Product Type | Piston Pin Bushing |
| Material | Bronze (copper/lead alloy) |
| Inside Diameter | Semi-finished (ream to fit) |
| Pack Count | 4 |
| Engine Configuration | I4 (pack = complete set) |
| Weight | 0.5 lbs |
| UPC | 707473088084 |
| Country of Origin | CN |
| OEM Cross-References | ACL: RB4028R, FEL-PRO: 4-3964Y, Topline: PBTO8, Safety Auto Parts Corp: BP15-060, MAHLE: 223-3612, DNJ: PB900 |
Vehicle Fitment
- 1975-1980 Toyota Celica 2.2L I4 SOHC [VIN:R]
- 1975-1980 Toyota Corona 2.2L I4 SOHC [VIN:R]
- 1975-1980 Toyota Pickup 2.2L I4 SOHC [VIN:R]
- 1981-1982 Toyota Corona 2.4L I4 SOHC [VIN:R]
- 1981-1983 Toyota Celica 2.4L I4 SOHC [VIN:R]
- 1981-1990 Toyota Pickup 2.4L I4 SOHC [VIN:R]
- 1983-1985 Toyota Celica 2.4L I4 SOHC [VIN:R]
- 1984 Toyota 4Runner 2.4L I4 SOHC [VIN:R]
- 1984-1988 Toyota Pickup 2.4L I4 SOHC [VIN:R]
- 1985-1988 Toyota 4Runner 2.4L I4 SOHC [VIN:R] Turbocharged
- 1985-1988 Toyota Pickup 2.4L I4 SOHC [VIN:R] Turbocharged
- 1985-1989 Toyota 4Runner 2.4L I4 SOHC [VIN:R]
- 1989-1995 Toyota Pickup 2.4L I4 SOHC [VIN:R]
- 1990-1995 Toyota 4Runner 2.4L I4 SOHC [VIN:R]
Enginetech Piston Pin Bushings are a copper/lead alloy bronze, cast to OE-equivalent specification for connecting rod small-end service. These bushings are supplied semi-finished on the inside diameter, meaning the ID must be final-reamed or honed to match the wrist pin after the bushing has been pressed into the rod - a standard rebuild-shop operation that ensures a precise running clearance on the piston pin. Each part number is engineered against the specific rod, pin, and bushing seat geometry of the listed applications, so cross-reference verification against the OEM part number is essential before installation.
WARNING: This product can expose you to chemicals including Lead and Nickel, which are known to the State of California to cause cancer, birth defects, or other reproductive harm.
