The Enginetech EM2503S exhaust valve features a 1.061" head diameter, 0.2345" stem (6mm nominal), and 3.957" overall length with Stellite-faced severe-service construction. Fits 1987-1992 Toyota 2.0L/2.2L applications.
Important Notes
- Sold individually as a single valve. Order the quantity required for your engine configuration (typically one per cylinder per valve position).
- Production date restriction: fits vehicles built through 1/92 only. Verify the production date on the VIN plate before ordering.
- Chrome-plated stem provides a hard, low-friction wear surface for extended service life.
- Stellite-faced construction is designed for severe-service exhaust temperatures and extended duty cycles typical of heavy-load or high-RPM operation.
- Always verify head diameter, stem diameter, overall valve length, and groove count against the OE valve being replaced before installation - valve dimensions vary across engine families and a visual match alone is not sufficient.
Specifications
| Part Number | EM2503S |
| Valve Type | Exhaust Valve |
| Head Diameter | 1.061" |
| Stem Diameter | 0.2345" (6mm nominal) |
| Valve Length | 3.957" OAL |
| Material | Stellite faced (severe-service) |
| Stem Finish | Chrome Stem |
| Number of Grooves | 1 |
| Weight | 0.25 lbs |
| OEM Cross-Refs | Elgin: EV2503, Fed. Mogul: V-2507X, ITM: RX9456, Manley: AX2503, Melling: V5320, QualCast: 10-10320S |
Vehicle Fitment
1987-1991 Toyota 2.0L / 1998 DOHC L4 16V 3SFE 86.00mm Bore; 1990-1992 Toyota 2.2L / 2164 DOHC L4 16V 5SFE 87.00mm Bore.
Product Video
Watch the Enginetech exhaust valve overview: https://youtu.be/G487Dw8HtII
Watch the Enginetech exhaust valve overview: https://youtu.be/eLaQHop7rH8
Enginetech standard valves are stock-replacement engine valves produced from OE grade materials or better, engineered with the production engine rebuilder in mind. Face runout, stem finish, and stem diameter tolerances are held to some of the tightest standards in the internal engine parts industry, and every valve is inspected by on-site engineers against a documented quality plan before it leaves the plant. The line covers domestic, import, and common high-performance applications across a full range of head diameters, stem diameters, and overall lengths, with chrome-plated and nitride-hardened stem finishes available where the engine's operating conditions call for the upgrade. Always verify head diameter, stem diameter, valve length, groove count, and any oversize stem requirement against the original valve being replaced before installing, as multiple valve configurations can share the same vehicle nameplate.
