Enginetech part number IM1014 is a direct-replacement intake valve for 2004-2016 Audi/Volkswagen 3.2L, 6.0L, 3.6L applications. Key specifications: 1.308" head, 0.2350" stem, 4.037" overall length.
Important Notes
- Short intake valve variant. This engine uses both short and long intake valves per cylinder - verify the length you need against the OE valve, and check whether you also need the companion long-intake part (often a sibling part number) for a complete head set.
- Always verify head diameter, stem diameter, and overall valve length against the OE valve being replaced before installation. Valve dimensions vary across engine families - a visual match is not enough.
Specifications
| Part Number | IM1014 |
| Valve Type | Intake Valve |
| Head Diameter | 1.308" |
| Stem Diameter | 0.2350" (6.00mm nominal) |
| Valve Length | 4.037" OAL |
| Number of Grooves | 3 |
| Weight | 1.50 lbs |
| OEM Cross-Refs | Audi: 022109601G, DNJ Rock: IV816, SBI: 13312, Topline: IVVW22, Volkswagen: 022109601G |
Vehicle Fitment
- 2004-2006 Audi 3.2L / 3189 DOHC V6 24V BHE,BUB,CBRA
- 2006-2009 Audi 3.2L / 3189 DOHC V6 24V BHE,BUB,CBRA
- 2012-2014 Audi 6.0L / 6229 DOHC W12 48V CEJA Natural Asp.
- 2015-2016 Audi 6.0L / 6229 DOHC W12 48V CTNA Natural Asp.
- 2007-2008 Volkswagen 3.2L / 3189 DOHC V6 24V
- 2006-2011 Volkswagen 3.6L / 3597 DOHC V6 24V BLV
- 2012-2016 Volkswagen 3.6L / 3597 DOHC V6 24V CDVB
- 2012-2016 Volkswagen 3.6L / 3597 DOHC V6 24V CNNA
- 2007-2010 Audi 3.6L / 3597 DOHC V6 24V BHK
- 2004-2006 Volkswagen 3.2L / 3189 DOHC V6 24V
- 2007-2010 Volkswagen 3.6L / 3597 DOHC V6 24V BHK
- 2011-2011 Volkswagen 3.6L / 3597 DOHC V6 24V CGRA
Product Video
Watch the Enginetech intake valve overview: https://youtu.be/G487Dw8HtII
Watch the Enginetech intake valve overview: https://youtu.be/eLaQHop7rH8
Enginetech standard valves are stock-replacement engine valves produced from OE grade materials or better, engineered with the production engine rebuilder in mind. Face runout, stem finish, and stem diameter tolerances are held to some of the tightest standards in the internal engine parts industry, and every valve is inspected by on-site engineers against a documented quality plan before it leaves the plant. The line covers domestic, import, and common high-performance applications across a full range of head diameters, stem diameters, and overall lengths, with chrome-plated and nitride-hardened stem finishes available where the engine's operating conditions call for the upgrade. Always verify head diameter, stem diameter, valve length, groove count, and any oversize stem requirement against the original valve being replaced before installing, as multiple valve configurations can share the same vehicle nameplate.
