Enginetech part number IM2398 is a direct-replacement intake valve for 1988-1994 Chrysler/Hyundai/Mitsubishi 1.5L applications. Key specifications: 1.374" head, 0.2586" stem, 4.000" overall length, chrome stem.
Important Notes
- Chrome-plated stem provides a hard, low-friction wear surface for extended service life.
- Always verify head diameter, stem diameter, and overall valve length against the OE valve being replaced before installation. Valve dimensions vary across engine families - a visual match is not enough.
Specifications
| Part Number | IM2398 |
| Valve Type | Intake Valve |
| Head Diameter | 1.374" |
| Stem Diameter | 0.2586" (6.50mm nominal) |
| Valve Length | 4.000" OAL |
| Stem Finish | Chrome Stem |
| Number of Grooves | 1 |
| Weight | 1.50 lbs |
| OEM Cross-Refs | Elgin: I2398, Fed. Mogul: V-4067, ITM: RV9388, Manley: S2398, Melling: V5136, QualCast: 10-10136 |
Vehicle Fitment
1988-1990 CHRYSLER 1.5L / 90 SOHC L4 8V "P,X" Mits. Fi.; 1990-1994 Hyundai 1.5L / 1468 SOHC L4 8V G4DJ; 1989-1990 Mitsubishi 1.5L / 1468 SOHC L4 8V "X" 4G15 Fi.; 1990-1994 Mitsubishi 1.5L / 1468 SOHC L4 8V "J" G4DJ Fi..
Product Video
Watch the Enginetech intake valve overview: https://youtu.be/G487Dw8HtII
Watch the Enginetech intake valve overview: https://youtu.be/eLaQHop7rH8
Enginetech standard valves are stock-replacement engine valves produced from OE grade materials or better, engineered with the production engine rebuilder in mind. Face runout, stem finish, and stem diameter tolerances are held to some of the tightest standards in the internal engine parts industry, and every valve is inspected by on-site engineers against a documented quality plan before it leaves the plant. The line covers domestic, import, and common high-performance applications across a full range of head diameters, stem diameters, and overall lengths, with chrome-plated and nitride-hardened stem finishes available where the engine's operating conditions call for the upgrade. Always verify head diameter, stem diameter, valve length, groove count, and any oversize stem requirement against the original valve being replaced before installing, as multiple valve configurations can share the same vehicle nameplate.
