The Holley Black Electric Fuel Pump 140 GPH Carbureted (part number 12-815-1). Street/Strip Carbureted Applications Compatible with Gasoline Only
Features:
- Tumble polished billet look
- Lower housing casting designed for enhanced fuel flow
- Improved design for street/strip applications
- Distinctive "Black" logo
- Not designed for use on aircraft of any type.
- Flows 140 GPH (free flow)
- Flows 120 GPH at 9 psi
- Maximum pressure is 14 psi
- 3/8" NPT inlet and outlet ports
- Fuel pressure regulator is required (recommend Holley P/N 12-704 for gasoline)
- Motor draws only 4 amps current
- Relay kit P/N 12-753 & 7 1/2 amp fuse recommended
- Provides constant fuel flow with no pulsation
- Has externally accessible pressure relief valve (max 14 psi)
- Rotor/vane pump design is more tolerant of contaminated fuels
- Weighs only 3 lbs
- Includes mounting bracket
- Repair kits are readily available
- Can be serviced from the pump end
- Use of safety shut-off switch, P/N 12-810, strongly recommended
- Not designed or recommended for use with fuel injection systems
Specifications:
| Number of Wires | 2 |
| Number of Terminals | 2 |
| Fit Type | Universal |
| Product Grade | Performance |
| Application | Automotive |
| Bracket Color | Silver |
| Color | Silver |
| Finish | Zinc |
| Free Flow GPH | 140 |
| Free Flow LPH | 530 |
| Fuel System | Carbureted |
| Inlet Fitting Thread Size | 3/8" |
| Material | Aluminum |
| Maximum Amperage Draw | 4 |
