The Fel-Pro ES 72170 is a cylinder head bolt set that secures the cylinder head to the engine block, clamping the head gasket to the correct load when torqued to the manufacturer's sequence and specification on the applications listed below, giving you correct-fit replacement hardware for the job.
| Brand | Fel-Pro |
| Part Number | ES 72170 |
| Product Type | Cylinder Head Bolt Set |
| Bolt Diameter | 11mm (Bolt 1); 11mm (Bolt 2) |
| Critical Length | 122.5mm (Bolt 1); 94mm (Bolt 2) |
| Thread Length | 52.5mm (Bolt 1); 60mm (Bolt 2) |
| Head Size | 15mm (Bolt 1); 15mm (Bolt 2) |
| Design | Replacement recommended |
| Engine | L4 (2.2L) |
| UPC | 614046359079 |
| Shipping Dimensions | 12.75 x 12.25 x 0.59 in, 0.36 lb |
Vehicle Fitment:
- 1998-2000 Isuzu Hombre 2.2L
- 1998-2002 Chevrolet Cavalier 2.2L
- 1998-2003 Chevrolet S10 2.2L
- 1998-2003 GMC Sonoma 2.2L
- 1998-2002 Pontiac Sunfire 2.2L
Important Notes:
- Torque the head bolts in the correct sequence and stages to the manufacturer's specification; many head bolts are torque-to-yield and should not be reused.
- Install a fresh head gasket set at the same time and clean the bolt holes before torquing.
- Verify the application and engine configuration against your engine before ordering; hardware is matched to specific engines.
