The Enginetech RCC395DP Engine Rebuild Kit is a complete overhaul package for the 1997-2002 Chevy 395 6.5L V8 (395 cid), machined to a 4.095" finished bore (.040" over bore).
Kit contents:
- P3054(8) - Piston Set
- S40518 - Piston Ring Set
- BB100J - Bearing Set - Rod
- BC102J - Bearing Set - Main
- CC420 - Bearing Set - Cam
- GM6.5HS-A - Gasket Set - Head
- GM6.5CS - Gasket Set - Lower
- TS181A - Timing Set
- EP255S - Oil Pump
- PK59 - Expansion Plug Kit
Component specifications:
- P3054(8) - Pistons: 2.106 Compression Height. Iron top groove
- S40518 - Piston rings: Premium. Steel or Ductile Moly. Keystone top. 3.0 / 2.0 / 4.0mm ring stack
- EP255S - Oil Pump: gear-type (spur gear), cast iron housing, high volume / standard pressure, 2-bolt mount
Bearing sizing: Select your rod and main bearing size. Rod and main bearings are supplied at the same size; contact us for different or split sizes.
Fits 1997-2002 6.5L 395 V8 engines for Chevy C3500HD, Chevy Express 2500, Chevy Express 3500, GMC C3500HD, GMC Savana 3500, GMC Savana 2500, Chevy K2500, Chevy C2500, and more. Verify fitment for your specific vehicle.
