The Monroe Shocks & Struts Magnum Rear Suspension Shock Absorber (part number 65416) is a direct-fit replacement for 1986-2008 GMC, Isuzu, and Kenworth vehicles with engines. Monroe Magnum 65416 Rear Suspension Shock Absorber
Features:
- INSTALLERS ADVANTAGE -- Designed to save time, simplify the job, fix OE design issues, solve customer complaints or enhances durability and longevity
- FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
- CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
- EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
- STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360 deg for durability
- BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
- LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
- REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
- IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
- BUY WITH CONFIDENCE -- Comes with Monroe's 90-day Risk Free Ride Offer and Limited Commercial Warranty
Specifications:
| Product Grade | Premium |
| Lower Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Lower Mount Code | LS54 |
| Upper Mount Type | Loop Bushing and Sleeve Mount - 3/4" Sleeve ID X 1.3/4" Sleeve OAL |
| Upper Mount Code | LS54 |
| Adjustable Damping | No |
| Part Description | Shock Absorber |
| Foam Cell Design | No |
| Shaft Diameter | 18 |
Fits: 1986-2008 GMC, Isuzu, and Kenworth models including T6500, T7500, FSR, FTR, FVR, T600A. Confirm your year, make, model, and engine before ordering.
Interchanges With: Highway Products A16135, Ridewell Corp 1270563B000, Duplex 59030, Strut-Mate 661104, Gabriel 83203, Hendrickson S20889, Hendrickson A20002, Meritor M85323 and 132 more
