The Holley EFI 6.86" M8 Pro Dash (part number 553-112X). Introducing the next era of Sniper 2 EFI displays. The new 6.86-inch and 12.3-inch dashes offer unparalleled customization and visibility. Fully compatible with all Sniper 2 EFI installations.
Features:
- Plug and play Support for All Sniper 2 EFI Systems
- Dedicated M8 CAN connection for Sniper 2 EFI
- 16 default background skins pre-loaded with unlimited options for importing custom layouts
- Configurable virtual switch panel with 4 user defined ground switched outputs
- Quickly swipe between multiple active screens for warmup, race, or whatever you want to monitor!
- No stylus required, capacitive touch, just like your smart phone
- Weatherproof aluminum housing featuring flexible mounting options
- Manual or auto-brightness features for easy viewing day or night
- Built-in GPS with odometer function (Antenna included)
- Expandable storage via USB (16GB memory stick included)
- Threaded mounting holes for surface or flush mounting, with high quality hardware included
- Includes everything needed for installation
- 4x 10-32 mounting holes for surface or flush mounting, with high quality hardware included!
- Includes everything needed for installation!
- USB Keyboard and Mouse functionality, makes it quick and easy to setup new layouts
- Upgradable with future software enhancements
- Wizard and tuning functions are not included within the Sniper 2 EFI Pro Dash Display
- 4ft M8 extension cable included
- Service harness part number 558-486 allows existing Pro Dash users to connect directly to the Sniper 2's M8 CAN connection
Specifications:
| Fit Type | Universal |
| Product Grade | Performance |
| Application | Sniper 2 M8 CAN |
| Depth | 1.25" |
| Height | 3.4375 |
| Maximum Gauge Diameter | Programmable |
| Minimum Gauge Diameter | Programmable |
| Screen Size | 6.86" |
| Screen Type | Capacitive Touch Screen |
| Width | 7.5625 |
