EFI 6.86 in. Pro Dash - Capacitive Touchscreen - 10-LED Shift Light 553-112

The Holley EFI 6.86" Pro Dash (part number 553-112). The Holley EFI 6.86" Pro Dash is customizable with a variety of gauge and indicator screens that can be programmed to display any parameter you need from a Holley EFI system.

Features:

• Plug-and-play Display support for Dominator, HP, Terminator X & Sniper EFI (not compatible with Sniper 2)
• Integrated a 10-LED Programmable shiftlight w/ 4-LED warning indicators for other sensor inputs
• Capable of monitoring up to 238 real-time values such as RPM/TPS/Boost
• 10 default background skins pre-loaded with unlimited options for importing custom layouts
• Quickly swipe between multiple active screens (tune, warm-up, race, drive, etc.)
• Virtual switch panel eliminates the need for external toggle switches
• Manual or auto-brightness features for easy viewing day or night
• Built-in GPS with odometer function (antenna included)
• On-screen datalog playback features allows you to review vital run information
• Expandable storage via USB
• No stylus required, utilizes capacitive touch just like your smart phone
• User definable channel alarms and warnings
• 4x 10-32 mounting holes for surface or flush mounting, with high quality hardware included
• Includes everything needed for installation
• USB keyboard and mouse functionality makes it quick and easy to setup new layouts
• Includes 34 Pin Wiring Harness contains Power, Ground and CANbus connections
• Input and output functionality for 13 multi-configurable inputs, and 4 ground switched outputs
• User defined alarms for any input
• Upgradable with future software enhancements
• Viewing area is 6.86" on the diagonal
• Dash weight - 1.2 Lbs
• Real-time ECU tuning - HP/Dominator ECUs only

Specifications:
