The CSF Radiator (part number 3210) is a direct-fit replacement for 1999-2003 Chevrolet, GMC, and Isuzu vehicles with 4.8L engines.
Features:
- OEM specified Plastic Tank-Aluminum Core Construction
- Tanks are made from Virgin Grade Engineered plastic resins, which are "Glass Filled" for added Strength & Durability
- Gaskets are made from Special Grade "EPDM" rubber to withstand extreme temperatures of up to -120 Degrees F
- Tubes - Welded Type or Latest Generation "B-Tube" Design
- Fins (Heart of Radiator) - High Performance "Multi-Louvered Design" - OEM Spec
- 100% leak tested before leaving factory at 150% of operating pressure
- Industry Best Packaging - "10 Foot Drop Test" Standard
- Drop-in Fit
Specifications:
| Box Length (in) | 30 1/4 |
| Box Width (in) | 28 7/8 |
| Box Height (in) | 6 14/16 |
| Box Weight (lbs) | 22 |
| Inlet Length (in) | 22 1/8 |
| Inlet Width (in) | 1 15/16 |
| Outlet Length (in) | 22 1/8 |
| Outlet Width (in) | 1 15/16 |
| No. Of Rows | 1 |
| Oil Cooler (in) | 14 3/8 (high-efficiency Plate Type) |
| Radiator Cap Supplied | No |
| Csf Cap Number | 4503 |
| Hazardous Material | No |
| Tech Note | O.E.M. Style Radiator; with sensor port on top tank. |
Fits: 1999-2003 Chevrolet, GMC, and Isuzu models including W3500 Tiltmaster, W4500 Tiltmaster, W5500 Tiltmaster, W3500 Forward, W4500 Forward, W5500 Forward, NPR, NPR-HD and more - 4.8L engines. Confirm your year, make, model, and engine before ordering.
Fitment Notes: OE #5-87410-784-0, 8-97213-664-1, 8-97354-362-1, 8-97354-365-0, 8-97730-088-0, 97213664, 97354362, 97354365, 97730088
Interchanges With: OEM Part Number 97213664, OEM Part Number 97354362, OEM Part Number 97354365, OEM Part Number 97730088, OEM Part Number 5-87410-784-0, OEM Part Number 8-97213-664-1, OEM Part Number 8-97354-362-1, OEM Part Number 8-97354-365-0 and 2 more
