Enginetech ESL1130 is a centrifugally cast iron cylinder repair sleeve with 3.586 inch bore, 6.500 inch length, 3/32 inch wall, cataloged for 1978-2005 Chrysler, Dodge, Hyundai and additional applications. It restores a damaged or over-bored cylinder to OE standard bore size without replacing the entire block.
Important Notes
- Sleeve is supplied with a semi-finished inside diameter; plan to remove at least 0.025 inch during final bore and hone to achieve the correct piston-to-wall clearance.
- Chamfered bottom outside diameter is intended to ease installation into the engine block; a light interference fit is typical and the block counterbore should be measured before pressing.
- Nominal wall thickness is 3/32 inch. Confirm the block counterbore diameter will accept the sleeve outside diameter before ordering.
- Sold individually; quantity required equals the number of cylinders being sleeved.
- Ships individually boxed and wrapped in rust-preventative paper.
| Part Number | ESL1130 |
| Bore Diameter | 3.586 in |
| Sleeve Length | 6.500 in |
| Wall Thickness | 3/32 in |
| Material | Cast Iron (Centrifugally Cast) |
| Finish | Semi-finished ID, chamfered bottom OD |
| OEM Cross-Refs | Melling:CSL1130 |
Vehicle Fitment
- 1978-1980 Dodge Colt 2.6L 156ci I4 SOHC
- 1978-1981 Mercedes-Benz 300CD 3.0L I5 SOHC
- 1978-1983 Dodge Challenger 2.6L 156ci I4 SOHC
- 1978-1983 Plymouth Sapporo 2.6L 156ci I4 SOHC
- 1979-1980 Plymouth Arrow 2.6L 156ci I4 SOHC
- 1979-1982 Dodge D50 2.6L 156ci I4 SOHC
- 1979-1982 Plymouth Arrow Pickup 2.6L 156ci I4 SOHC
- 1981-1985 Dodge Aries 2.6L 156ci I4 SOHC
- 1981-1985 Plymouth Reliant 2.6L 156ci I4 SOHC
- 1982 Mercedes-Benz 300CD 3.0L I5 SOHC Turbocharged
- 1982-1983 Dodge 400 2.6L 156ci I4 SOHC
- 1982-1985 Chrysler LeBaron 2.6L 156ci I4 SOHC
- 1982-1985 Chrysler Town & Country 2.6L 156ci I4 SOHC
- 1983-1984 Chrysler E Class 2.6L 156ci I4 SOHC
- 1983-1984 Chrysler Executive Sedan 2.6L 156ci I4 SOHC
- 1983-1985 Chrysler New Yorker 2.6L 156ci I4 SOHC
- 1983-1985 Dodge 600 2.6L 156ci I4 SOHC
- 1983-1989 Mitsubishi Mighty Max 2.6L 156ci I4 SOHC
- 1983-1989 Mitsubishi Montero 2.6L 156ci I4 SOHC
- 1983-1989 Mitsubishi Starion 2.6L 156ci I4 SOHC Turbocharged
- ...and 47 additional applications
Enginetech cylinder sleeves are centrifugally cast engine block repair components available in a full range of bore diameters and lengths, supplied in standard 3/32 inch and 1/8 inch wall thicknesses. Centrifugal casting produces homogenous material throughout each sleeve for consistent hardness and machinability, and every sleeve is supplied with a semi-finished inside diameter that allows the machinist to remove at least 0.025 inch during boring and honing for a precision bore-to-piston fit. A chamfered bottom OD edge eases installation into the block, and each sleeve ships individually boxed and wrapped in rust-preventative paper for clean shelf storage. Enginetech also produces high-performance sleeves cast from a premium formula yielding higher hardness (293 BHN) and higher tensile strength (45,000 PSI) where the application demands it. Always verify bore diameter, sleeve length, and wall thickness against the damaged cylinder before ordering.
