Enginetech ESL116 is a centrifugally cast iron cylinder repair sleeve with 3.910 inch bore, 6.000 inch length, 3/32 inch wall, cataloged for 1957-2022 Chrysler, Dodge, Jeep and additional applications. It restores a damaged or over-bored cylinder to OE standard bore size without replacing the entire block.
Important Notes
- Sleeve is supplied with a semi-finished inside diameter; plan to remove at least 0.025 inch during final bore and hone to achieve the correct piston-to-wall clearance.
- Chamfered bottom outside diameter is intended to ease installation into the engine block; a light interference fit is typical and the block counterbore should be measured before pressing.
- Nominal wall thickness is 3/32 inch. Confirm the block counterbore diameter will accept the sleeve outside diameter before ordering.
- Sold individually; quantity required equals the number of cylinders being sleeved.
- Ships individually boxed and wrapped in rust-preventative paper.
| Part Number | ESL116 |
| Bore Diameter | 3.910 in |
| Sleeve Length | 6.000 in |
| Wall Thickness | 3/32 in |
| Material | Cast Iron (Centrifugally Cast) |
| Finish | Semi-finished ID, chamfered bottom OD |
| Country of Origin | Colombia |
| Weight | 3 lbs |
| UPC | 707473103091 |
| OEM Cross-Refs | Melling:CSL116, MAHLE:ML116 |
Vehicle Fitment
- 1957-1962, 1978 Plymouth Fury 5.2L 318ci V8 OHV
- 1959 Dodge Truck 5.2L 318ci V8 OHV
- 1959, 1968-1974 Dodge D100 Pickup 5.2L 318ci V8 OHV
- 1959, 1968-1974 Dodge D200 Pickup 5.2L 318ci V8 OHV
- 1959, 1968-1974 Dodge D300 Pickup 5.2L 318ci V8 OHV
- 1959, 1968-1974 Dodge W100 Pickup 5.2L 318ci V8 OHV
- 1959, 1968-1974 Dodge W200 Pickup 5.2L 318ci V8 OHV
- 1959, 1968-1974 Dodge W300 Pickup 5.2L 318ci V8 OHV
- 1960 Dodge D100 Series 5.2L 318ci V8 OHV
- 1960 Dodge D200 Series 5.2L 318ci V8 OHV
- 1960 Dodge D300 Series 5.2L 318ci V8 OHV
- 1960 Dodge Matador 5.2L 318ci V8 OHV
- 1960 Dodge Phoenix 5.2L 318ci V8 OHV
- 1960 Dodge Pioneer 5.2L 318ci V8 OHV
- 1960 Dodge Seneca 5.2L 318ci V8 OHV
- 1960 Dodge Truck 5.2L 318ci V8 OHV
- 1960 Dodge W100 Series 5.2L 318ci V8 OHV
- 1960 Dodge W200 Series 5.2L 318ci V8 OHV
- 1960 Dodge W300 Series 5.2L 318ci V8 OHV
- 1960 Dodge Wm300 Power Wagon 5.2L 318ci V8 OHV
- ...and 327 additional applications
Enginetech cylinder sleeves are centrifugally cast engine block repair components available in a full range of bore diameters and lengths, supplied in standard 3/32 inch and 1/8 inch wall thicknesses. Centrifugal casting produces homogenous material throughout each sleeve for consistent hardness and machinability, and every sleeve is supplied with a semi-finished inside diameter that allows the machinist to remove at least 0.025 inch during boring and honing for a precision bore-to-piston fit. A chamfered bottom OD edge eases installation into the block, and each sleeve ships individually boxed and wrapped in rust-preventative paper for clean shelf storage. Enginetech also produces high-performance sleeves cast from a premium formula yielding higher hardness (293 BHN) and higher tensile strength (45,000 PSI) where the application demands it. Always verify bore diameter, sleeve length, and wall thickness against the damaged cylinder before ordering.
