Enginetech ESL1174 is a centrifugally cast iron cylinder repair sleeve with 4.110 inch bore, 7.500 inch length, 3/32 inch wall, cataloged for 1988-2003 Ford, International applications. It restores a damaged or over-bored cylinder to OE standard bore size without replacing the entire block.
Important Notes
- Sleeve is supplied with a semi-finished inside diameter; plan to remove at least 0.025 inch during final bore and hone to achieve the correct piston-to-wall clearance.
- Chamfered bottom outside diameter is intended to ease installation into the engine block; a light interference fit is typical and the block counterbore should be measured before pressing.
- Nominal wall thickness is 3/32 inch. Confirm the block counterbore diameter will accept the sleeve outside diameter before ordering.
- Sold individually; quantity required equals the number of cylinders being sleeved.
- Ships individually boxed and wrapped in rust-preventative paper.
| Part Number | ESL1174 |
| Bore Diameter | 4.110 in |
| Sleeve Length | 7.500 in |
| Wall Thickness | 3/32 in |
| Material | Cast Iron (Centrifugally Cast) |
| Finish | Semi-finished ID, chamfered bottom OD |
| Country of Origin | Colombia |
| Weight | 3.5 lbs |
| UPC | 707473103114 |
Vehicle Fitment
- 1988 International S1754 7.3L 444ci V8 Turbocharged
- 1988-1989 International 1654 7.3L 444ci V8
- 1988-1989 International S1654 7.3L 444ci V8 Turbocharged
- 1988-1989 International S1654LP 7.3L 444ci V8 Turbocharged
- 1988-1989 International S1753 7.3L 444ci V8 Turbocharged
- 1988-1990 International M1400 Metro II 7.3L 444ci V8 Turbocharged
- 1988-1990 International M1600 Metro II 7.3L 444ci V8 Turbocharged
- 1988-1991 Ford E-250 Econoline Club Wagon 7.3L 445ci V8 OHV [VIN:M]
- 1988-1992 International 1452SC 7.3L 444ci V8
- 1988-1993 International 1652SC 7.3L 444ci V8
- 1988-1994 Ford E-350 Econoline 7.3L 445ci V8 OHV [VIN:M] Naturally Aspirated, Turbocharged
- 1988-1994 Ford E-350 Econoline Club Wagon 7.3L 445ci V8 OHV [VIN:M] Naturally Aspirated, Turbocharged
- 1988-1994 Ford F-250 7.3L 445ci V8 OHV [VIN:M]
- 1988-1994 Ford F-350 7.3L 445ci V8 OHV [VIN:M]
- 1990 International 3800 7.3L 444ci V8 Turbocharged
- 1990 International 4600 7.3L 444ci V8
- 1990 International 4600UH 7.3L 444ci V8 Turbocharged
- 1990-1991, 1993 International 1652UPS 7.3L 444ci V8 Turbocharged
- 1990-1993 International 3700 7.3L 444ci V8 Turbocharged
- 1990-1993 International 4600LP 7.3L 444ci V8 Turbocharged
- ...and 39 additional applications
Enginetech cylinder sleeves are centrifugally cast engine block repair components available in a full range of bore diameters and lengths, supplied in standard 3/32 inch and 1/8 inch wall thicknesses. Centrifugal casting produces homogenous material throughout each sleeve for consistent hardness and machinability, and every sleeve is supplied with a semi-finished inside diameter that allows the machinist to remove at least 0.025 inch during boring and honing for a precision bore-to-piston fit. A chamfered bottom OD edge eases installation into the block, and each sleeve ships individually boxed and wrapped in rust-preventative paper for clean shelf storage. Enginetech also produces high-performance sleeves cast from a premium formula yielding higher hardness (293 BHN) and higher tensile strength (45,000 PSI) where the application demands it. Always verify bore diameter, sleeve length, and wall thickness against the damaged cylinder before ordering.
