Enginetech ESL197 is a centrifugally cast iron cylinder repair sleeve with 4.250 inch bore, 7.000 inch length, 3/32 inch wall, cataloged for 1959-2000 Chevrolet, Chrysler, Dodge and additional applications. It restores a damaged or over-bored cylinder to OE standard bore size without replacing the entire block.
Important Notes
- Sleeve is supplied with a semi-finished inside diameter; plan to remove at least 0.025 inch during final bore and hone to achieve the correct piston-to-wall clearance.
- Chamfered bottom outside diameter is intended to ease installation into the engine block; a light interference fit is typical and the block counterbore should be measured before pressing.
- Nominal wall thickness is 3/32 inch. Confirm the block counterbore diameter will accept the sleeve outside diameter before ordering.
- Sold individually; quantity required equals the number of cylinders being sleeved.
- Ships individually boxed and wrapped in rust-preventative paper.
| Part Number | ESL197 |
| Bore Diameter | 4.250 in |
| Sleeve Length | 7.000 in |
| Wall Thickness | 3/32 in |
| Material | Cast Iron (Centrifugally Cast) |
| Finish | Semi-finished ID, chamfered bottom OD |
| Country of Origin | Colombia |
| Weight | 3.25 lbs |
| UPC | 707473103329 |
Vehicle Fitment
- 1959 Chrysler Saratoga 6.3L 383ci V8 OHV
- 1959 Chrysler Windsor 6.3L 383ci V8 OHV
- 1959 Dodge Coronet 6.3L 383ci V8
- 1959 Dodge Custom 6.3L 383ci V8 OHV
- 1959 Dodge Lancer 6.3L 383ci V8 OHV
- 1959 Dodge Royal 6.3L 383ci V8 OHV
- 1959 Dodge Sierra 6.3L 383ci V8 OHV
- 1960 Chrysler Saratoga 6.3L 383ci V8 OHV
- 1960 Chrysler Windsor 6.3L 383ci V8 OHV
- 1960 Dodge Custom 6.3L 383ci V8 OHV
- 1960 Dodge Dart 6.3L 383ci V8 OHV
- 1960 Dodge Matador 6.3L 383ci V8 OHV
- 1960 Dodge Phoenix 6.3L 383ci V8 OHV
- 1960 Plymouth Belvedere 6.3L 383ci V8 OHV
- 1960 Plymouth Custom 6.3L 383ci V8 OHV
- 1960 Plymouth Fleet Special 6.3L 383ci V8 OHV
- 1960 Plymouth Savoy 6.3L 383ci V8 OHV
- 1960 Plymouth Sport Wagon 6.3L 383ci V8 OHV
- 1960 Plymouth Suburban 6.3L 383ci V8 OHV
- 1960-1964 Dodge Polara 6.3L 383ci V8
- ...and 337 additional applications
Enginetech cylinder sleeves are centrifugally cast engine block repair components available in a full range of bore diameters and lengths, supplied in standard 3/32 inch and 1/8 inch wall thicknesses. Centrifugal casting produces homogenous material throughout each sleeve for consistent hardness and machinability, and every sleeve is supplied with a semi-finished inside diameter that allows the machinist to remove at least 0.025 inch during boring and honing for a precision bore-to-piston fit. A chamfered bottom OD edge eases installation into the block, and each sleeve ships individually boxed and wrapped in rust-preventative paper for clean shelf storage. Enginetech also produces high-performance sleeves cast from a premium formula yielding higher hardness (293 BHN) and higher tensile strength (45,000 PSI) where the application demands it. Always verify bore diameter, sleeve length, and wall thickness against the damaged cylinder before ordering.
