Enginetech ESL120 is a centrifugally cast iron cylinder repair sleeve with 3.750 inch bore, 7.250 inch length, 3/32 inch wall, cataloged for 1955-1990 American Motors, Ford, Jeep and additional applications. It restores a damaged or over-bored cylinder to OE standard bore size without replacing the entire block.
Important Notes
- Sleeve is supplied with a semi-finished inside diameter; plan to remove at least 0.025 inch during final bore and hone to achieve the correct piston-to-wall clearance.
- Chamfered bottom outside diameter is intended to ease installation into the engine block; a light interference fit is typical and the block counterbore should be measured before pressing.
- Nominal wall thickness is 3/32 inch. Confirm the block counterbore diameter will accept the sleeve outside diameter before ordering.
- Sold individually; quantity required equals the number of cylinders being sleeved.
- Ships individually boxed and wrapped in rust-preventative paper.
| Part Number | ESL120 |
| Bore Diameter | 3.750 in |
| Sleeve Length | 7.250 in |
| Wall Thickness | 3/32 in |
| Material | Cast Iron (Centrifugally Cast) |
| Finish | Semi-finished ID, chamfered bottom OD |
| Country of Origin | Colombia |
| Weight | 4.25 lbs |
| UPC | 707473103121 |
Vehicle Fitment
- 1955 Mercury Custom 4.8L 292ci V8 OHV [VIN:P]
- 1955 Mercury Montclair 4.8L 292ci V8 OHV [VIN:P]
- 1955 Mercury Monterey 4.8L 292ci V8 OHV [VIN:P]
- 1955-1956 Ford Customline 4.8L 292ci V8 OHV [VIN:P]
- 1955-1956 Ford Mainline 4.8L 292ci V8 OHV [VIN:P]
- 1955-1957 Ford Club 4.8L 292ci V8 OHV [VIN:P]
- 1955-1957 Ford Fairlane 4.8L 292ci V8 OHV [VIN:P]
- 1955-1957 Ford Skyliner 4.8L 292ci V8 OHV [VIN:P]
- 1955-1957 Ford Sunliner 4.8L 292ci V8 OHV [VIN:P]
- 1955-1957 Ford Thunderbird 4.8L 292ci V8 OHV [VIN:P]
- 1955-1957 Ford Victoria 4.8L 292ci V8 OHV [VIN:P]
- 1955-1962 Ford Country Sedan 4.8L 292ci V8 OHV
- 1955-1962 Ford Country Squire 4.8L 292ci V8 OHV
- 1955-1962 Ford Ranch Wagon 4.8L 292ci V8 OHV
- 1956 Ford Club 4.8L 292ci V8 OHV [VIN:M]
- 1956 Ford Customline 4.8L 292ci V8 OHV [VIN:M]
- 1956 Ford Fairlane 4.8L 292ci V8 OHV [VIN:M]
- 1956 Ford Mainline 4.8L 292ci V8 OHV [VIN:M]
- 1956 Ford Park Lane Wagon 4.8L 292ci V8 OHV [VIN:M]
- 1956 Ford Park Lane Wagon 4.8L 292ci V8 OHV [VIN:P]
- ...and 171 additional applications
Enginetech cylinder sleeves are centrifugally cast engine block repair components available in a full range of bore diameters and lengths, supplied in standard 3/32 inch and 1/8 inch wall thicknesses. Centrifugal casting produces homogenous material throughout each sleeve for consistent hardness and machinability, and every sleeve is supplied with a semi-finished inside diameter that allows the machinist to remove at least 0.025 inch during boring and honing for a precision bore-to-piston fit. A chamfered bottom OD edge eases installation into the block, and each sleeve ships individually boxed and wrapped in rust-preventative paper for clean shelf storage. Enginetech also produces high-performance sleeves cast from a premium formula yielding higher hardness (293 BHN) and higher tensile strength (45,000 PSI) where the application demands it. Always verify bore diameter, sleeve length, and wall thickness against the damaged cylinder before ordering.
