Enginetech ESL181 is a centrifugally cast iron cylinder repair sleeve with 3.875 inch bore, 6.250 inch length, 3/32 inch wall, cataloged for 1957-2006 American Motors, Buick, Chevrolet and additional applications. It restores a damaged or over-bored cylinder to OE standard bore size without replacing the entire block.
Important Notes
- Sleeve is supplied with a semi-finished inside diameter; plan to remove at least 0.025 inch during final bore and hone to achieve the correct piston-to-wall clearance.
- Chamfered bottom outside diameter is intended to ease installation into the engine block; a light interference fit is typical and the block counterbore should be measured before pressing.
- Nominal wall thickness is 3/32 inch. Confirm the block counterbore diameter will accept the sleeve outside diameter before ordering.
- Sold individually; quantity required equals the number of cylinders being sleeved.
- Ships individually boxed and wrapped in rust-preventative paper.
| Part Number | ESL181 |
| Bore Diameter | 3.875 in |
| Sleeve Length | 6.250 in |
| Wall Thickness | 3/32 in |
| Material | Cast Iron (Centrifugally Cast) |
| Finish | Semi-finished ID, chamfered bottom OD |
| Country of Origin | Colombia |
| Weight | 2.75 lbs |
| UPC | 707473103312 |
| OEM Cross-Refs | Melling:CSL181, MAHLE:ML181 |
Vehicle Fitment
- 1957 Chevrolet One-Fifty Series 4.6L 283ci V8 OHV
- 1957 Chevrolet Two-Ten Series 4.6L 283ci V8 OHV
- 1957-1958 Chevrolet Del Ray 4.6L 283ci V8 OHV
- 1957-1958 Chevrolet Sedan Delivery 4.6L 283ci V8 OHV
- 1957-1958 Chevrolet Truck 4.6L 283ci V8 OHV
- 1957-1961 Chevrolet Corvette 4.6L 283ci V8 OHV
- 1957-1967 Chevrolet Bel Air 4.6L 283ci V8 OHV
- 1957-1967 Pontiac Laurentian 4.6L 283ci V8 OHV
- 1958 Chevrolet Yeoman 4.6L 283ci V8 OHV
- 1958-1967 Chevrolet Biscayne 4.6L 283ci V8 OHV
- 1958-1967 Chevrolet Impala 4.6L 283ci V8 OHV
- 1959 Chevrolet 3B 4.6L 283ci V8 OHV
- 1959 Chevrolet 3C 4.6L 283ci V8 OHV
- 1959 Chevrolet 3D 4.6L 283ci V8 OHV
- 1959 Chevrolet 3E 4.6L 283ci V8 OHV
- 1959 Chevrolet 3F 4.6L 283ci V8 OHV
- 1959 Chevrolet 3G 4.6L 283ci V8 OHV
- 1959-1960 Chevrolet El Camino 4.6L 283ci V8 OHV
- 1959-1961 Chevrolet Brookwood 4.6L 283ci V8 OHV
- 1959-1961 Chevrolet Kingswood 4.6L 283ci V8 OHV
- ...and 173 additional applications
Enginetech cylinder sleeves are centrifugally cast engine block repair components available in a full range of bore diameters and lengths, supplied in standard 3/32 inch and 1/8 inch wall thicknesses. Centrifugal casting produces homogenous material throughout each sleeve for consistent hardness and machinability, and every sleeve is supplied with a semi-finished inside diameter that allows the machinist to remove at least 0.025 inch during boring and honing for a precision bore-to-piston fit. A chamfered bottom OD edge eases installation into the block, and each sleeve ships individually boxed and wrapped in rust-preventative paper for clean shelf storage. Enginetech also produces high-performance sleeves cast from a premium formula yielding higher hardness (293 BHN) and higher tensile strength (45,000 PSI) where the application demands it. Always verify bore diameter, sleeve length, and wall thickness against the damaged cylinder before ordering.
