Enginetech ESL124 is a centrifugally cast iron cylinder repair sleeve with 3.680 inch bore, 6.000 inch length, 3/32 inch wall, cataloged for 1963-1993 Buick, Ford, Mercury and additional applications. It restores a damaged or over-bored cylinder to OE standard bore size without replacing the entire block.
Important Notes
- Sleeve is supplied with a semi-finished inside diameter; plan to remove at least 0.025 inch during final bore and hone to achieve the correct piston-to-wall clearance.
- Chamfered bottom outside diameter is intended to ease installation into the engine block; a light interference fit is typical and the block counterbore should be measured before pressing.
- Nominal wall thickness is 3/32 inch. Confirm the block counterbore diameter will accept the sleeve outside diameter before ordering.
- Sold individually; quantity required equals the number of cylinders being sleeved.
- Ships individually boxed and wrapped in rust-preventative paper.
| Part Number | ESL124 |
| Bore Diameter | 3.680 in |
| Sleeve Length | 6.000 in |
| Wall Thickness | 3/32 in |
| Material | Cast Iron (Centrifugally Cast) |
| Finish | Semi-finished ID, chamfered bottom OD |
| Country of Origin | Colombia |
| Weight | 2.5 lbs |
| UPC | 707473103145 |
| OEM Cross-Refs | Melling:CSL124, MAHLE:ML124 |
Vehicle Fitment
- 1963 Ford 300 3.3L 200ci I6 OHV [VIN:T]
- 1963 Ford Galaxie 3.3L 200ci I6 OHV [VIN:T]
- 1963 Ford Galaxie 500 3.3L 200ci I6 OHV [VIN:T]
- 1963 Mercury Country Cruiser 3.3L 200ci I6 OHV [VIN:T]
- 1963 Mercury Meteor 3.3L 200ci I6 OHV [VIN:T]
- 1963-1964 Ford Sprint 3.3L 200ci I6 OHV [VIN:T]
- 1963-1969 Ford Fairlane 3.3L 200ci I6 OHV
- 1963-1969, 1971-1974 Mercury Comet 3.3L 200ci I6 OHV
- 1963-1970 Ford Ranch Wagon 3.3L 200ci I6 OHV [VIN:T]
- 1964 Mercury Cyclone 3.3L 200ci I6 OHV [VIN:T]
- 1964-1965 Ford Falcon Sedan Delivery 3.3L 200ci I6 OHV [VIN:T]
- 1964-1967 Mercury Caliente 3.3L 200ci I6 OHV [VIN:T]
- 1964-1967 Mercury Villager 3.3L 200ci I6 OHV [VIN:T]
- 1964-1968 Ford Ranchero 3.3L 200ci I6 OHV [VIN:T]
- 1964-1970 Ford Falcon 3.3L 200ci I6 OHV
- 1964-1970 Ford Mustang 3.3L 200ci I6 OHV
- 1965-1970 Ford Country Sedan 3.3L 200ci I6 OHV [VIN:T]
- 1965-1970 Ford Country Squire 3.3L 200ci I6 OHV [VIN:T]
- 1966-1967 Mercury Voyager 3.3L 200ci I6 OHV [VIN:T]
- 1966-1967, 1979 Mercury Capri 3.3L 200ci I6 OHV [VIN:T]
- ...and 50 additional applications
Enginetech cylinder sleeves are centrifugally cast engine block repair components available in a full range of bore diameters and lengths, supplied in standard 3/32 inch and 1/8 inch wall thicknesses. Centrifugal casting produces homogenous material throughout each sleeve for consistent hardness and machinability, and every sleeve is supplied with a semi-finished inside diameter that allows the machinist to remove at least 0.025 inch during boring and honing for a precision bore-to-piston fit. A chamfered bottom OD edge eases installation into the block, and each sleeve ships individually boxed and wrapped in rust-preventative paper for clean shelf storage. Enginetech also produces high-performance sleeves cast from a premium formula yielding higher hardness (293 BHN) and higher tensile strength (45,000 PSI) where the application demands it. Always verify bore diameter, sleeve length, and wall thickness against the damaged cylinder before ordering.
