Enginetech ESL145 is a centrifugally cast iron cylinder repair sleeve with 3.710 inch bore, 7.750 inch length, 3/32 inch wall, cataloged for 1953-1964 Ford, GMC applications. It restores a damaged or over-bored cylinder to OE standard bore size without replacing the entire block.
Important Notes
- Sleeve is supplied with a semi-finished inside diameter; plan to remove at least 0.025 inch during final bore and hone to achieve the correct piston-to-wall clearance.
- Chamfered bottom outside diameter is intended to ease installation into the engine block; a light interference fit is typical and the block counterbore should be measured before pressing.
- Nominal wall thickness is 3/32 inch. Confirm the block counterbore diameter will accept the sleeve outside diameter before ordering.
- Sold individually; quantity required equals the number of cylinders being sleeved.
- Ships individually boxed and wrapped in rust-preventative paper.
| Part Number | ESL145 |
| Bore Diameter | 3.710 in |
| Sleeve Length | 7.750 in |
| Wall Thickness | 3/32 in |
| Material | Cast Iron (Centrifugally Cast) |
| Finish | Semi-finished ID, chamfered bottom OD |
| OEM Cross-Refs | Melling:CSL145 |
Vehicle Fitment
- 1953-1955 GMC 100 4.1L 248ci I6 OHV
- 1954 GMC 100-24 4.1L 248ci I6 OHV
- 1954 GMC 150-24 4.1L 248ci I6 OHV
- 1954 GMC 250-24 4.1L 248ci I6 OHV
- 1954 GMC 300-24 4.1L 248ci I6 OHV
- 1954 GMC 350-24 4.1L 248ci I6 OHV
- 1954 GMC 350-27 4.1L 248ci I6 OHV
- 1954 GMC F350-24 4.1L 248ci I6 OHV
- 1954 GMC F350-27 4.1L 248ci I6 OHV
- 1954 GMC M350-24 4.1L 248ci I6 OHV
- 1954 GMC M350-27 4.1L 248ci I6 OHV
- 1954 GMC P150-22 4.1L 248ci I6 OHV
- 1954 GMC PM150-22 4.1L 248ci I6 OHV
- 1954 GMC PM150-24 4.1L 248ci I6 OHV
- 1954 GMC PM152-22 4.1L 248ci I6 OHV
- 1954 GMC PM250-24 4.1L 248ci I6 OHV
- 1954 GMC S300-24 4.1L 248ci I6 OHV
- 1954-1955 GMC 100-22 4.1L 248ci I6 OHV
- 1954-1955 GMC 150 4.1L 248ci I6 OHV
- 1954-1955 GMC 150-22 4.1L 248ci I6 OHV
- ...and 16 additional applications
Enginetech cylinder sleeves are centrifugally cast engine block repair components available in a full range of bore diameters and lengths, supplied in standard 3/32 inch and 1/8 inch wall thicknesses. Centrifugal casting produces homogenous material throughout each sleeve for consistent hardness and machinability, and every sleeve is supplied with a semi-finished inside diameter that allows the machinist to remove at least 0.025 inch during boring and honing for a precision bore-to-piston fit. A chamfered bottom OD edge eases installation into the block, and each sleeve ships individually boxed and wrapped in rust-preventative paper for clean shelf storage. Enginetech also produces high-performance sleeves cast from a premium formula yielding higher hardness (293 BHN) and higher tensile strength (45,000 PSI) where the application demands it. Always verify bore diameter, sleeve length, and wall thickness against the damaged cylinder before ordering.
