Enginetech ESL5000 is a centrifugally cast iron cylinder repair sleeve with 3.551 inch bore, 6.500 inch length, 3/32 inch wall, cataloged for 1991-2019 Ford, Lincoln, Mercury applications. It restores a damaged or over-bored cylinder to OE standard bore size without replacing the entire block.
Important Notes
- Sleeve is supplied with a semi-finished inside diameter; plan to remove at least 0.025 inch during final bore and hone to achieve the correct piston-to-wall clearance.
- Chamfered bottom outside diameter is intended to ease installation into the engine block; a light interference fit is typical and the block counterbore should be measured before pressing.
- Nominal wall thickness is 3/32 inch. Confirm the block counterbore diameter will accept the sleeve outside diameter before ordering.
- Sold individually; quantity required equals the number of cylinders being sleeved.
- Ships individually boxed and wrapped in rust-preventative paper.
| Part Number | ESL5000 |
| Bore Diameter | 3.551 in |
| Sleeve Length | 6.500 in |
| Wall Thickness | 3/32 in |
| Material | Cast Iron (Centrifugally Cast) |
| Finish | Semi-finished ID, chamfered bottom OD |
| Country of Origin | Colombia |
| Weight | 2.5 lbs |
| UPC | 707473103510 |
Vehicle Fitment
- 1991-2011 Lincoln Town Car 4.6L 281ci V8
- 1992-2010 Mercury Grand Marquis 4.6L 281ci V8 SOHC [VIN:W]
- 1992-2011 Ford Crown Victoria 4.6L 281ci V8 SOHC [VIN:W]
- 1994-1997 Ford Thunderbird 4.6L 281ci V8 SOHC [VIN:W]
- 1994-1997 Mercury Cougar 4.6L 281ci V8 SOHC [VIN:W]
- 1996 Ford Crown Victoria 4.6L 281ci V8 SOHC [VIN:6]
- 1996 Mercury Grand Marquis 4.6L 281ci V8 SOHC [VIN:6]
- 1996-2004 Ford Mustang 4.6L 281ci V8 SOHC [VIN:X]
- 1996-2005 Ford Crown Victoria 4.6L 281ci V8 SOHC [VIN:9]
- 1997-1998 Ford E-150 Econoline Club Wagon 4.6L 281ci V8 SOHC [VIN:6]
- 1997-1998 Ford E-350 Econoline 6.8L 415ci V10 SOHC [VIN:S]
- 1997-1999 Ford E-150 Econoline 4.6L 281ci V8 SOHC [VIN:6]
- 1997-1999 Ford Econoline Super Duty 6.8L 415ci V10 SOHC [VIN:S]
- 1997-1999 Ford F-250 4.6L 281ci V8 SOHC [VIN:6]
- 1997-1999 Ford F-250 4.6L 281ci V8 SOHC [VIN:W]
- 1997-1999, 2002-2003 Ford F-150 4.6L 281ci V8 SOHC [VIN:6]
- 1997-2000 Ford Expedition 4.6L 281ci V8 SOHC [VIN:6]
- 1997-2002 Ford E-350 Econoline Club Wagon 6.8L 415ci V10 SOHC [VIN:S]
- 1997-2004 Ford Expedition 4.6L 281ci V8 SOHC [VIN:W]
- 1997-2004 Ford Expedition 5.4L 330ci V8 SOHC [VIN:L]
- ...and 32 additional applications
Enginetech cylinder sleeves are centrifugally cast engine block repair components available in a full range of bore diameters and lengths, supplied in standard 3/32 inch and 1/8 inch wall thicknesses. Centrifugal casting produces homogenous material throughout each sleeve for consistent hardness and machinability, and every sleeve is supplied with a semi-finished inside diameter that allows the machinist to remove at least 0.025 inch during boring and honing for a precision bore-to-piston fit. A chamfered bottom OD edge eases installation into the block, and each sleeve ships individually boxed and wrapped in rust-preventative paper for clean shelf storage. Enginetech also produces high-performance sleeves cast from a premium formula yielding higher hardness (293 BHN) and higher tensile strength (45,000 PSI) where the application demands it. Always verify bore diameter, sleeve length, and wall thickness against the damaged cylinder before ordering.
