Enginetech ESL5006 is a centrifugally cast iron cylinder repair sleeve with 4.0157 inch bore, 7.875 inch length, 0.050 inch wall, cataloged for 1989-2009 Dodge applications. It restores a damaged or over-bored cylinder to OE standard bore size without replacing the entire block.
Important Notes
- Sleeve is supplied with a semi-finished inside diameter; plan to remove at least 0.025 inch during final bore and hone to achieve the correct piston-to-wall clearance.
- Chamfered bottom outside diameter is intended to ease installation into the engine block; a light interference fit is typical and the block counterbore should be measured before pressing.
- Nominal wall thickness is 0.050 inch (thin-wall). Verify block counterbore diameter and sleeve OD clearance before pressing.
- Sold individually; quantity required equals the number of cylinders being sleeved.
- Ships individually boxed and wrapped in rust-preventative paper.
| Part Number | ESL5006 |
| Bore Diameter | 4.0157 in |
| Sleeve Length | 7.875 in |
| Wall Thickness | 0.050 in |
| Material | Cast Iron (Centrifugally Cast) |
| Finish | Semi-finished ID, chamfered bottom OD |
| Country of Origin | Colombia |
Vehicle Fitment
- 1989-1991 Dodge D250 5.9L 359ci I6 OHV [VIN:8] Turbocharged
- 1989-1991 Dodge D350 5.9L 359ci I6 OHV [VIN:8] Turbocharged
- 1989-1991 Dodge W250 5.9L 359ci I6 OHV [VIN:8] Turbocharged
- 1989-1991 Dodge W350 5.9L 359ci I6 OHV [VIN:8] Turbocharged
- 1991-1992 Dodge D350 5.9L 359ci I6 OHV [VIN:C] Turbocharged
- 1991-1993 Dodge D250 5.9L 359ci I6 OHV [VIN:C] Turbocharged
- 1991-1993 Dodge W250 5.9L 359ci I6 OHV [VIN:C] Turbocharged
- 1992-1993 Dodge W350 5.9L 359ci I6 OHV [VIN:C] Turbocharged
- 1994-1996, 2002-2007 Dodge Ram 3500 5.9L 359ci I6 OHV [VIN:C] Turbocharged
- 1994-1996, 2002-2009 Dodge Ram 2500 5.9L 359ci I6 OHV [VIN:C] Turbocharged
- 1997-1998 Dodge Ram 2500 5.9L 359ci I6
- 1997-1998 Dodge Ram 3500 5.9L 359ci I6 OHV [VIN:D] Turbocharged
- 1998-2004 Dodge Ram 2500 5.9L 359ci I6 OHV [VIN:6] Turbocharged
- 1998-2004 Dodge Ram 3500 5.9L 359ci I6 OHV [VIN:6] Turbocharged
- 2001 Dodge Ram 2500 5.9L 359ci I6 OHV [VIN:7] Turbocharged
- 2001-2002 Dodge Ram 3500 5.9L 359ci I6 OHV [VIN:7] Turbocharged
Enginetech cylinder sleeves are centrifugally cast engine block repair components available in a full range of bore diameters and lengths, supplied in standard 3/32 inch and 1/8 inch wall thicknesses. Centrifugal casting produces homogenous material throughout each sleeve for consistent hardness and machinability, and every sleeve is supplied with a semi-finished inside diameter that allows the machinist to remove at least 0.025 inch during boring and honing for a precision bore-to-piston fit. A chamfered bottom OD edge eases installation into the block, and each sleeve ships individually boxed and wrapped in rust-preventative paper for clean shelf storage. Enginetech also produces high-performance sleeves cast from a premium formula yielding higher hardness (293 BHN) and higher tensile strength (45,000 PSI) where the application demands it. Always verify bore diameter, sleeve length, and wall thickness against the damaged cylinder before ordering.
